BRIGHTSIGN-DS400

OUTDOOR DOUBLE SIDED

Description

  • Firefly Visual Double-sided Outdoor Advertising Screen-Brightsign DS400, with LCD display on one side of the product and lightbox on the other side, can well meet customers’ various display needs at the same time. The outstanding appearance design can attract the attention of the crowd very well and is often used in bus stations, scenic spots, and other public places with large crowds. And the Brightsign DS400 LCD Outdoor Totem is also equipped with an advanced anti-theft lock design, which is more secure and reliable.
    The high brightness of the Outdoor Dual Sided-Brightsign DS400 is 7 to 10 times higher than that of a standard home TV. It can improve the image clarity of the display in an outdoor environment. No matter the weather, the pedestrians in the past can clearly get the content on the outdoor advertising screen.

Features

  • IP55/IP65
  • Automatic brightness control
  • Automatic temperature control
  • Support open door maintenance
  • Double sided scree design option
  • One side screen and one side light box design option

Reference Dimension

  • 75″: 2250*1030*300mm(H*W*D)

Operating enviromentOutdoor dual sided kioskSpecifications
OutdoorPANELDisplay55"65"75"86"
Screen Size
Panel TechnologyIPS,M+(WRGB)IPS,M+(WRGB)IPS,M+(WRGB)IPS,M+(WRGB)
Back light typeWLEDWLEDWLEDWLED
Asper Ratio16:0916:0916:0916:09
Native resdution1080*19202160*38402160*38402160*3840
Brightness2000~3000nits2000~3000nits2000~3000nits2000~2500nits
contrast Ratio1200:11200:11200:11200:1
Dynamic CRCR≥10CR≥10CR≥10CR≥10
Viewing Angle(H*V)178*178178*178178*178178*178
Response time6ms8ms8ms8ms
Surface Treatment(Haze.Quater Wave plate) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H)
Life Time(Type)50,000 h - 60000 h50,000 h - 60000 h50,000 h - 60000 h50,000 h - 60000 h
Operation Hours24h24h24h24h
Orientation Portrait & Landscape Portrait & Landscape Portrait & Landscape Portrait & Landscape
ConnectivityInputHDMI,  VGA, USB*2HDMI,DP,VGA,AUDIO,USBHDMI,DP,VGA,AUDIO,USBHDMI,DP,VGA,AUDIO,USB
OutputExternal Speaker Out(L/R)External Speaker Out(L/R)External Speaker Out(L/R)External Speaker Out(L/R)
External ControlRJ45RJ45RJ45RJ45
PHYSICAL SPECIFICATIONProtection Glass 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective)
Bezel ColorBlack/SilverBlack/SilverBlack/SilverBlack/Silver
KEY FEATURETemperature Sensor, Auto Brightness sensor
ENVIRONMENTCONDITIONSOperation Temperature.-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner)
Operation Humidity.-10°C-80°C.-10°C-80°C.-10°C-80°C.-10°C-80°C
POWERPower Supply 100-240V~, 50/60Hz 100-240V~, 50/60Hz 100-240V~, 50/60Hz 100-240V~, 50/60Hz
Power TypeBuilt-In PowerBuilt-In PowerBuilt-In PowerBuilt-In Power
POWERCONSUMPTIONTyp./Max.2000nits260W/360W335W/520W390W/600W850W/1200W
2500nits320W/445W420W/580W490W/700W1000W/1450W
3000nits370W/510W480W/720W570W/800W
SOFTWARECOMPATIBILITYSuperSignYes(CMS, Control)Yes(CMS, Control)Yes(CMS, Control)Yes(CMS, Control)
ACCESSORYBasic
