BRIGHTSIGN-DS200

Outdoor floor standing LCD signage

Description

  • BRIGHTSIGN-DS200 all-glass double-sided outdoor advertising screen with high-brightness LCD displays on both sides. This style is usually large in size, which is very suitable for large outdoor applications, and the all-glass design is suitable for some high-end places. A good automatic brightness screen and temperature control can ensure that the display screen operates normally for a long time while maintaining high performance. The sealed glass doors of the outdoor LCD display on both sides can perfectly protect the internal LCD display, and the special opening design is very convenient for daily maintenance and repair.

Features

  • IP55/IP65
  • Automatic brightness control
  • Automatic temperature control
  • Support open door maintenance
  • Double sided screen design option
  • One side screen and one side light box design option

Reference Dimension

  • 65″:2250*1030*300mm(H*W*D)


Operating enviromentOutdoor dual sided kioskSpecifications
OutdoorPANELDisplay55"65"75"86"
Screen Size
Panel TechnologyIPS,M+(WRGB)IPS,M+(WRGB)IPS,M+(WRGB)IPS,M+(WRGB)
Back light typeWLEDWLEDWLEDWLED
Asper Ratio16:0916:0916:0916:09
Native resdution1080*19202160*38402160*38402160*3840
Brightness2000~3000nits2000~3000nits2000~3000nits2000~2500nits
contrast Ratio1200:11200:11200:11200:1
Dynamic CRCR≥10CR≥10CR≥10CR≥10
Viewing Angle(H*V)178*178178*178178*178178*178
Response time6ms8ms8ms8ms
Surface Treatment(Haze.Quater Wave plate) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H) (Haze 3%)，Hard coating (2H)
Life Time(Type)50,000 h - 60000 h50,000 h - 60000 h50,000 h - 60000 h50,000 h - 60000 h
Operation Hours24h24h24h24h
Orientation Portrait & Landscape Portrait & Landscape Portrait & Landscape Portrait & Landscape
ConnectivityInputHDMI,  VGA, USB*2HDMI,DP,VGA,AUDIO,USBHDMI,DP,VGA,AUDIO,USBHDMI,DP,VGA,AUDIO,USB
OutputExternal Speaker Out(L/R)External Speaker Out(L/R)External Speaker Out(L/R)External Speaker Out(L/R)
PHYSICAL SPECIFICATIONProtection Glass 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective) 6mm for naomal products.8mm(IK 10, Degree of Protection, Tempered,Anti-Reflective)
Bezel ColorBlack/SilverBlack/SilverBlack/SilverBlack/Silver
KEY FEATURETemperature Sensor, Auto Brightness sensor
ENVIRONMENTCONDITIONSOperation Temperature.-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner).-20°C to 40 °C with fans;-30°C to 50 °C with air conditioner)
Operation Humidity.-10°C-80°C.-10°C-80°C.-10°C-80°C.-10°C-80°C
POWERPower Supply 100-240V~, 50/60Hz 100-240V~, 50/60Hz 100-240V~, 50/60Hz 100-240V~, 50/60Hz
Power TypeBuilt-In PowerBuilt-In PowerBuilt-In PowerBuilt-In Power
POWERCONSUMPTIONTyp./Max.2000nits260W/360W335W/520W390W/600W850W/1200W
2500nits320W/445W420W/580W490W/700W1000W/1450W
3000nits370W/510W480W/720W570W/800W
CERTIFICATIONSafetyPSEPSEPSEPSE
EMCPSE/VCCIPSE/VCCIPSE/VCCIPSE/VCCI
SOFTWARECOMPATIBILITYSuperSignYes(CMS, Control)Yes(CMS, Control)Yes(CMS, Control)Yes(CMS, Control)
